The ADP160AUJZ-3.3-R7 is a highly efficient, low quiescent current linear regulator manufactured by Analog Devices Inc. Designed to maintain precision voltage control, this component is ideal for portable and battery-powered applications where energy efficiency is paramount.

Key Features

• Output Voltage: Fixed 3.3V output, providing a stable voltage for consistent operation.
• High Accuracy: Ensures tight regulation with an accuracy of ±1%, contributing to the reliable performance of the end application.
• Low Dropout: Offers a low dropout performance, which enhances efficiency by allowing operation closer to the battery voltage.
• Quiescent Current: Ultra-low Iq of 11 µA (typical), which is crucial for prolonging battery life in portable devices.
• Thermal Overload Protection: Incorporates safety features that shut down the regulator to prevent damage from overheating.
• Package: Available in a compact TSOT-5 package, making it suitable for space-constrained applications.

Applications

The ADP160AUJZ-3.3-R7 is versatile and can be used in a variety of applications, including but not limited to:

• Mobile Phones
• Personal Digital Assistants (PDAs)
• Digital Cameras
• Portable Media Players
• Wireless LAN Devices
• GPS Receivers

Technical Specifications

The ADP160AUJZ-3.3-R7's combination of high accuracy, low dropout, and ultra-low quiescent current makes it an excellent choice for powering sensitive electronic components that require a stable voltage source with minimal power loss.
