Introducing the TMP36FSZ-REEL Temperature Sensor from Analog Devices Inc.

The TMP36FSZ-REEL is a precision centigrade temperature sensor from Analog Devices Inc., a leader in high-performance analog, mixed-signal, and digital signal processing integrated circuits. This sensor provides a linear temperature output with a scaling factor of 10 mV/°C, ensuring easy interfacing to temperature control circuits and microcontrollers without the need for additional calibration. Designed for low voltage, high accuracy temperature measurements, the TMP36FSZ-REEL is an ideal solution for a wide range of applications.

With its low operating voltage range of 2.7 V to 5.5 V, this sensor is perfect for battery-powered systems and portable devices. Its low quiescent current of just 50 µA (maximum at 25 °C) makes it an energy-efficient option for always-on monitoring in power-sensitive applications. Furthermore, the TMP36FSZ-REEL is characterized for operation over a temperature range of -40°C to +125°C, providing reliable performance across a broad range of environmental conditions.

The sensor comes in a versatile and easy-to-solder 3-lead SOT-23 package, which is an industry-standard footprint. The TMP36FSZ-REEL version is supplied in tape and reel form, making it suitable for automated assembly processes, thus reducing manufacturing time and cost.

Key features of the TMP36FSZ-REEL include:

• Linear temperature scaling of 10 mV/°C
• Wide operating voltage range of 2.7 V to 5.5 V
• Low quiescent current of 50 µA max
• Calibrated directly in °C
• Rated for a wide temperature range: -40°C to +125°C
• Low shutdown current of 0.5 µA max
• Accurate to ±2°C at room temperature
• 3-lead SOT-23 package suitable for automated assembly

Whether you are developing environmental control systems, building monitoring equipment, or creating consumer products that require temperature feedback, the TMP36FSZ-REEL from Analog Devices Inc. offers a dependable and straightforward solution for integrating temperature sensing into your design. Its precision, low power consumption, and ease of use make it an excellent choice for engineers and product designers who demand high-quality sensor technology.
