HCPL-7800A-000E

Name: HCPL-7800A-000E
Brand: Broadcom Limited
SKU: 142092
Availability: InStock
Rating: 4.85 (48 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	HCPL-7800A-000E
Manufacturer	Broadcom Limited
Catalog	Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description	IC OPAMP ISOLATION 100KHZ 8DIP
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Integrated Circuits
Manufacturer	Broadcom Limited
Packaging	Tube/Rail
Status	Active
Amplifier Type	Isolation
Number of Circuits	1
-3db Bandwidth	100kHz
Current - Input Bias	500nA
Voltage - Input Offset	300μV
Operating Supply Current	10.9mA
Channel Output Current	16mA
Supply Voltage - Operating	4.5 V to 5.5 V
Temperature Range - Operating	-40°C to 85°C
Mounting	Through Hole
Case / Package	8-DIP
Win Source Part Number	016882-HCPL-7800A-000E
Family Name	HCPL-7800A
Introduction Date	May 31, 2005
ECCN	EAR99
Country of Origin	Thailand
Halogen Free	Not Compliant
Estimated EOL Date	2022
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Quantity per package	50
Ultra Librarian 3D Model	Ultra Librarian HCPL-7800A-000E CAD Model

Description

The Broadcom Limited 016882-HCPL-7800A-000E is an active optocoupler with one circuit and an isolation amplifier type.

-3db Bandwidth: 100kHz
Current Input Bias: 500nA
Voltage Input Offset: 300μV
Mounting: Through Hole
Package: 8-DIP
Operating Temperature: -40°C to 85°C
Supply Voltage: 4.5V to 5.5V
Channel Output Current: 16mA
Operating Supply Current: 10.9mA
Package Quantity: 50
