Same model may have multiple batches, images only for reference.
MPQ3725 Central Semiconductor Corp
Same model may have multiple batches, images only for reference.

MPQ3725

Part No MPQ3725
Manufacturer Central Semiconductor Corp
Catalog Transistors (BJT) - Arrays
Description TRANS 4NPN 40V 1A
Datasheet
MPQ3725 Datasheet
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Central Semiconductor Corp
Packaging Tube/Rail
Status Active
Transistor Polarity 4 NPN (Quad)
Maximum Current Collector 1A
VCEO Maximum Collector-Emitter Breakdown Voltage 40V
Max Vce (sat) 450mV @ 50mA, 500mA
Collector Cut-off Current(Max) 500nA (ICBO)
Typical Gain (hFE) (Min) 35 @ 100mA, 1V
Maximum Power Dissipation 1W
Frequency - Transition 250MHz
Temperature Range - Operating -65°C to 150°C (TJ)
Mounting Through Hole
Case / Package TO-116
Win Source Part Number 044991-MPQ3725
Ultra Librarian 3D Model Ultra Librarian MPQ3725 CAD Model

Description

The MPQ3725 is a quad NPN transistor from Central Semiconductor Corp. It has a maximum collector-emitter breakdown voltage of 40V and a maximum current collector of 1A.

  • Type: Quad NPN
  • Maximum Collector-Emitter Breakdown Voltage: 40V
  • Maximum Current Collector: 1A
  • Application: Discrete Semiconductor Products
  • Transition Frequency: 250MHz
  • Mounting Type: Through Hole
  • Case / Package: TO-116
  • Typical Gain (hFE): 35 @ 100mA, 1V
  • Maximum Power Dissipation: 1W
  • Collector Cut-Off Current (max): 500nA (ICBO)
  • Maximum Vce (sat): 450mV @ 50mA, 500mA
  • Product Status: Active
  • Operating Temperature: -65°C to 150°C (TJ)
