CFM-A225B-230-438-20 Real Image
Same model may have multiple batches, images only for reference.

CFM-A225B-230-438-20

Part No CFM-A225B-230-438-20
Manufacturer CUI Inc.
Catalog Fans, Thermal Management
Description FAN AXIAL 120X25.4MM 24VDC WIRE / Fan Tubeaxial 24VDC Square - 120mm L x 120mm H Ball 104.6 CFM (2.93m³/min) 3 Wire Leads
Datasheet
CFM-A225B-230-438-20 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Fans, Thermal Management - Fans - DC Brushless Fans (BLDC)
Mfr CUI Devices
Series CFM-120B
Package Box
Voltage - Rated 24VDC
Size / Dimension Square - 120mm L x 120mm H
Width 25.40mm
Air Flow 104.6 CFM (2.93m³/min)
Static Pressure 0.210 in H2O (52.3 Pa)
Bearing Type Ball
Fan Type Tubeaxial
Features Auto Restart, Speed Sensor (Tach)
Noise 46.6dB(A)
Power (Watts) 7.2 W
RPM 3000 RPM
Termination 3 Wire Leads
Temperature Range - Operating 14 ~ 158°F (-10 ~ 70°C)
Approval Agency CE, cURus, TUV
Current Rating (Amps) 0.300A
Voltage Range 4.5 ~ 5.5VDC
Material - Frame Polybutylene Terephthalate (PBT)
Material - Blade Polybutylene Terephthalate (PBT)
Lifetime @ Temp. 70000 Hrs @ 40°C
Standard Package 30
MSL Level Not Applicable
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8414.59.6590
Win Source Part Number 1350768-CFM-A225B-230-438-20
Ultra Librarian 3D Model Ultra Librarian CFM-A225B-230-438-20 CAD Model

Description

The CUI Devices CFM-120B series DC brushless fan, CFM-A225B-230-438-20, is a square-shaped fan with a size of 120mm x 120mm.

  • Size: 120mm x 120mm
  • Voltage Rating: 24VDC
  • Power Rating: 7.2W
  • Features: speed sensor (tach) and auto restart
  • Air Flow: 104.6 CFM (2.93m³/min)
  • Static Pressure: 0.210 in H2O (52.3 Pa)
  • Noise Level: 46.6dB(A)
  • Operating Temperature Range: 14°F to 158°F (-10°C to 70°C)
  • Approvals: CE, cURus, and TUV
