The AP7346D-3333FS6-7 from Diodes Incorporated is a cutting-edge, dual-channel low dropout regulator (LDO), designed to deliver high-performance stabilization in a compact package. With its advanced features, this LDO is an ideal choice for powering sensitive microprocessors, microcontrollers, and other digital systems that require a stable and precise voltage supply.

Key Features

• Dual Output: This LDO provides two regulated outputs, each capable of delivering up to 150mA of continuous current, making it suitable for simultaneous dual voltage applications.
• High Accuracy: It boasts an impressive output voltage accuracy of ±1%, ensuring reliable operation for precision-dependent components.
• Low Dropout: The low dropout voltage of typically just 250mV at 150mA load contributes to its high efficiency, especially beneficial in battery-operated devices where power conservation is critical.
• Wide Operating Voltage Range: The AP7346D-3333FS6-7 operates over a broad input voltage range from 2.7V to 5.25V, accommodating a variety of power sources and system voltages.
• Thermal Shutdown Protection: Built-in thermal shutdown functionality ensures that the device is protected from overheating, enhancing its reliability and longevity.
• Current Limit Protection: The integrated current limit protection guards against excessive currents that could otherwise damage the LDO or the powered device.

Applications

With its dual-output configuration and robust protection features, the AP7346D-3333FS6-7 is well-suited for a wide array of applications, including:

• Portable and battery-powered devices
• Smartphones and tablets
• Wearable technology
• IoT devices
• Healthcare monitoring systems
• Power management for sensitive electronic circuits

Package and Availability

The device comes in a compact, space-saving 6-pin SOT-26 package, ensuring minimal footprint on PCBs. The product reference AP7346D-3333FS6-7 signifies the specific configuration and packaging, and it is available for order through Diodes Incorporated's distribution network.
