Product Overview: AZ1117S-ADJTRE1 from Diodes Incorporated

The AZ1117S-ADJTRE1 is a high-performance, low-dropout linear regulator designed and manufactured by Diodes Incorporated, a leading global provider of discrete, logic, analog, and mixed-signal semiconductors. This regulator offers an adjustable output voltage, making it versatile for a wide range of applications in the electronics industry.

Key Features

• Adjustable Output Voltage: The device provides an adjustable output voltage that ranges from 1.25V to 13.8V, which can be set by external resistors. This feature makes it suitable for various applications requiring different voltage levels.
• High Efficiency: With a low dropout voltage of typically 1.1V at 1A, the AZ1117S-ADJTRE1 ensures efficient operation, especially in systems where the difference between the input and output voltage is small.
• Current Limiting and Thermal Protection: The built-in current limiting and thermal shutdown features protect the device and the system from damage due to overcurrent and overheating conditions.
• Wide Input Voltage Range: It can support an input voltage range from 2.7V to 15V, accommodating a broad spectrum of power sources.
• Stable Operation: The regulator is stable with output capacitance as low as 10μF, which can be ceramic, tantalum, or aluminum electrolytic, offering flexibility in design choices.
• Surface-Mount Package: The AZ1117S-ADJTRE1 comes in a small footprint SOT-223 package, which is ideal for space-constrained applications.

Applications

The adjustable nature of the AZ1117S-ADJTRE1 makes it a perfect fit for a variety of electronic devices and systems. It is commonly used in:

• High-efficiency linear power supplies
• Battery-powered devices
• Post-regulation for switching supplies
• Portable consumer electronics
• Computer peripherals
• Telecommunication equipment

Quality and Reliability

Diodes Incorporated is known for its commitment to quality, and the AZ1117S-ADJTRE1 is no exception. It is designed to meet the rigorous standards of the electronics industry, ensuring reliable performance in a variety of operating conditions.

In conclusion, the AZ1117S-ADJTRE1 from Diodes Incorporated is a versatile, efficient, and reliable solution for applications requiring a regulated power supply with an adjustable output voltage. Its comprehensive feature set and robust protection mechanisms make it a top choice for designers looking to enhance the performance and safety of their electronic systems.
