The B130LAW-7-F is a high-quality Schottky barrier rectifier from Diodes Incorporated, renowned for its low forward voltage drop and high efficiency. Designed to meet the stringent requirements of modern electronic equipment, this rectifier is an ideal choice for applications requiring fast switching and low power loss.

Key Features

• Low Forward Voltage Drop: The device offers a low forward voltage drop, which reduces power loss and improves efficiency, making it suitable for high-frequency applications.
• High Current Capability: With a forward continuous current of 1A, the B130LAW-7-F can handle high levels of current, making it suitable for a wide range of applications.
• Power Dissipation: The rectifier has a power dissipation of 410mW, which ensures that the device can sustain moderate power levels without overheating.
• Low Reverse Leakage Current: Its low reverse leakage current minimizes power waste when the diode is in the reverse-biased state.
• Surface Mount Package: The B130LAW-7-F comes in a compact SOD-123 package, which is ideal for space-constrained applications and allows for efficient automated assembly.

Applications

The B130LAW-7-F is versatile and can be used in a variety of applications, including:

• Power supply units
• DC-DC converters
• Free-wheeling diodes in converters and motor control circuits
• Polarity protection applications
• Portable devices and battery charging circuits

Quality and Reliability

Diodes Incorporated is committed to providing high-quality products. The B130LAW-7-F is manufactured with the highest standards, ensuring reliability and performance in even the most demanding situations. It is RoHS compliant and adheres to the rigorous industry standards for environmental safety and sustainability.

Summary

The B130LAW-7-F Schottky barrier rectifier is a highly efficient solution for your rectification needs. With its low forward voltage drop, high current capability, and surface mount design, it is perfectly suited for modern electronic applications that demand high efficiency and compactness. Diodes Incorporated's commitment to quality ensures that this product will perform reliably for a wide array of applications.
