BC556BBK Real Image
Same model may have multiple batches, images only for reference.

BC556BBK

Part No BC556BBK
Manufacturer DIOTEC Electronics Corporation
Catalog Transistors (BJT) - Single
Description TRANS PNP 65V 0.1A TO92 / Bipolar (BJT) Transistor PNP 65 V 100 mA 150MHz 500 mW Through Hole TO-92
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products>Transistors - Bipolar (BJT) - Single
Manufacturer Diotec Semiconductor
Packaging Strip
Transistor Type PNP
Current - Collector (Ic) (Max) 100 mA
Voltage - Collector Emitter Breakdown (Max) 65 V
Vce Saturation (Max) @ Ib, Ic 650mV @ 5mA, 100mA
Current - Collector Cutoff (Max) 15nA
DC Current Gain (hFE) (Min) @ Ic, Vce 200 @ 2mA, 5V
Power - Max 500 mW
Frequency - Transition 150MHz
Temperature Range - Operating -55°C ~ 150°C (TJ)
Mounting Through Hole
Case / Package TO-226-3, TO-92-3 (TO-226AA)
Supplier Device Package TO-92
RoHS Status ROHS3 Compliant
Other Part Number 2721-BC556BBK
Standard Package 30
Win Source Part Number 1324222-BC556BBK
Ultra Librarian 3D Model Ultra Librarian BC556BBK CAD Model

Description

The BC556BBK is a PNP bipolar transistor from Diotec Semiconductor.

  • Maximum Power: 500mW
  • Voltage Breakdown (Collector-Emitter): 65V
  • Maximum Collector Current: 100mA
  • Vce Saturation: 650mV @ 5mA, 100mA
  • DC Current Gain: 200 @ 2mA, 5V
  • Cutoff Current: 15nA
  • Frequency Transition: 150MHz
  • Package: TO-92
  • Operating Temperature: -55°C to 150°C (TJ)
