FDBL0240N100 Real Image FDBL0240N100 real image21464
Same model may have multiple batches, images only for reference.
FDBL0240N100 Real Image FDBL0240N100 real image21464
FDBL0240N100 Real Image FDBL0240N100 real image21464
Same model may have multiple batches, images only for reference.

FDBL0240N100

Part No FDBL0240N100
Manufacturer Fairchild/ON Semiconductor
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 100V 210A POWER56
Datasheet
FDBL0240N100 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Fairchild/ON Semiconductor
Series PowerTrench
Packaging Reel package
Channel Type Type N
Technology MOSFET
Drain Source Voltage 100V
Current - Continuous Drain (Id) @ 25°C 210A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Vgs(th) (Maximum) @ Id 4V @ 250μA
Gate Charge (Qg) (Maximum) @ Vgs 111nC @ 10V
Input Capacitance (Ciss) (Maximum) @ Vds 8755pF @ 50V
Vgs (Maximum) ±20V
Power Dissipation (Maximum) 3.5W (Ta), 300W (Tc)
Rds On (Maximum) @ Id, Vgs 2.8 mOhm @ 80A, 10V
Operating Temperature Range -55°C ~ 175°C (TJ)
Mounting SMD
Manufacturer Package 8-PSOF
Package 8-PowerSFN
Win Source Part Number 763564-FDBL0240N100
Popularity Medium
Supply and Demand Status Limited
Quantity per package 2k pcs
Family Name FDBL0240N100
ECCN EAR99
Country of Origin Philippines
Halogen Free Compliant
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian FDBL0240N100 CAD Model

Description

The FDBL0240N100 is a MOSFET from Fairchild/ON Semiconductor. It is a part of the PowerTrench series and is packaged in a 8-PowerSFN package.

  • Series: PowerTrench
  • Package: 8-PowerSFN
  • Temperature Range: -55°C to 175°C (TJ)
  • Current Rating: 210A (Tc)
  • Drain-Source Voltage: 100V
  • Gate Charge: 111nC @ 10V
  • Input Capacitance: 8755pF @ 50V
  • Rds On (Maximum) @ Id, Vgs: 2.8 mOhm @ 80A, 10V
  • ROHS3 Compliant: Yes
  • ECCN: EAR99
