FDC6305N Real Image FDC6305N Real Image1 FDC6305N Real Image2 FDC6305N Real Image3 FDC6305N Real Image4
Same model may have multiple batches, images only for reference.
FDC6305N Real Image FDC6305N Real Image1 FDC6305N Real Image2 FDC6305N Real Image3 FDC6305N Real Image4
FDC6305N Real Image FDC6305N Real Image1 FDC6305N Real Image2 FDC6305N Real Image3 FDC6305N Real Image4
Same model may have multiple batches, images only for reference.

FDC6305N

Part No FDC6305N
Manufacturer Fairchild/ON Semiconductor
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET 2N-CH 20V 2.7A SSOT6
Datasheet
FDC6305N Datasheet
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
FET Type 2 N-Channel (Dual)
FET Feature Logic Level Gate
Drain-Source Breakdown Voltage 20V
Continuous Drain Current at 25°C 2.7A
Maximum Rds On at Id,Vgs 80 mOhm @ 2.7A, 4.5V
Gate-Source Threshold Voltage 1.5V @ 250μA
Max Gate Charge 5nC @ 4.5V
Max Input Capacitance 310pF @ 10V
Maximum Power Dissipation 700mW
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package SuperSOT-6
Win Source Part Number 001134-FDC6305N
Family Name FDC6305N
Introduction Date June 08, 1999
ECCN EAR99
Country of Origin Philippines
Halogen Free Compliant
Estimated EOL Date 2024
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Industrial, Motor Drive & Control, Power Management
Quantity per package 3k pcs
Ultra Librarian 3D Model Ultra Librarian FDC6305N CAD Model

Description

FDC6305N Description

The FDC6305N is a high-performance MOSFET optimized for fast switching and efficient energy management. It is ideal for use in a range of switching applications.

Applications

  • Switching regulators
  • Motor drives
  • Level shifting applications

Features and Benefits

  • Superior fast switching characteristics
  • High energy efficiency
  • Compact packaging for ease of integration

Additional Details

With its robust construction, the FDC6305N is designed to handle challenging environments, providing reliability and performance over an extended lifespan.
