Same model may have multiple batches, images only for reference.

FDMC7692

Name: FDMC7692
Brand: Fairchild/ON Semiconductor
SKU: 129365
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

Part No	FDMC7692
Manufacturer	Fairchild/ON Semiconductor
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET N-CH 30V 8-MLP
Datasheet	FDMC7692 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Fairchild/ON Semiconductor
Packaging	Reel - TR
Status	Active
Polarity	N-Channel
Technology	MOSFET
Drain-Source Breakdown Voltage	30V
Continuous Drain Current at 25°C	12.5A (Ta), 18A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	4.5V, 10V
Gate-Source Threshold Voltage	3V @ 1mA
Max Gate Charge	23nC @ 10V
Max Input Capacitance	1385pF @ 15V
Maximum Gate-Source Voltage	±20V
Power Dissipation (Max)	2.3W (Ta), 27W (Tc)
Maximum Rds On at Id,Vgs	9.3 mOhm @ 12.5A, 10V
Temperature Range - Operating	-55°C to 150°C (TJ)
Mounting	SMD (SMT)
Case / Package	8-MLP (3.3x3.3)
Dimension	8-PowerWDFN
Win Source Part Number	093197-FDMC7692
Family Name	FDMC7692
Introduction Date	July 01, 2009
ECCN	EAR99
Country of Origin	Philippines, Taiwan, Thailand
Halogen Free	Compliant
Estimated EOL Date	2024
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Sufficient
Quantity per package	3k pcs
Ultra Librarian 3D Model	Ultra Librarian FDMC7692 CAD Model

Alternative Products

Description

The Fairchild/ON Semiconductor FDMC7692 is an N-channel MOSFET transistor with a drain-source breakdown voltage of 30V.

Drain-Source Breakdown Voltage: 30V
Maximum Continuous Drain Current: 12.5A (Ta), 18A (Tc)
Maximum Rds On at Id,Vgs: 9.3 mOhm @ 12.5A, 10V
Operating Temperature: -55°C to 150°C (TJ)
Package: 8-MLP (3.3x3.3)
Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V

It is commonly used in various discrete semiconductor product applications.
