FDMC7696

Name: FDMC7696
Brand: Fairchild/ON Semiconductor
SKU: 129367
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	FDMC7696
Manufacturer	Fairchild/ON Semiconductor
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET N-CH 30V 20A POWER33 / Trans MOSFET N-CH Si 30V 12A 8-Pin WDFN EP T/R
Datasheet	FDMC7696 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Fairchild/ON Semiconductor
Packaging	Reel - TR
Status	Active
Polarity	N-Channel
Technology	MOSFET
Drain-Source Breakdown Voltage	30V
Continuous Drain Current at 25°C	12A (Ta), 20A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	4.5V, 10V
Gate-Source Threshold Voltage	3V @ 250μA
Max Gate Charge	22nC @ 10V
Max Input Capacitance	1430pF @ 15V
Maximum Gate-Source Voltage	±20V
Power Dissipation (Max)	2.4W (Ta), 25W (Tc)
Maximum Rds On at Id,Vgs	11.5 mOhm @ 12A, 10V
Temperature Range - Operating	-55°C to 150°C (TJ)
Mounting	SMD (SMT)
Case / Package	8-MLP (3.3x3.3)
Dimension	8-PowerWDFN
Win Source Part Number	066978-FDMC7696
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Limited
Quantity per package	3k pcs
Family Name	FDMC7696
Introduction Date	September 17, 2010
ECCN	EAR99
Country of Origin	Philippines
Halogen Free	Compliant
Estimated EOL Date	2027
Ultra Librarian 3D Model	Ultra Librarian FDMC7696 CAD Model

Alternative Products

Description

The Fairchild/ON Semiconductor FDMC7696 is a MOSFET transistor with N-Channel polarity. The supply and demand status of this component is limited.
