The FDS9945NL is a complementary N-Channel and P-Channel PowerTrench® MOSFET from Fairchild Semiconductor (now ON Semiconductor). It is designed for use in a variety of power management and switching applications. The combination of N and P channel MOSFETs in a single package allows for efficient implementation of push-pull drivers, load switches, and other circuit configurations where both high-side and low-side switching are required. The device is optimized for low on-resistance and fast switching speeds.

Applications:

• Load switching in portable devices.
• Power management in battery-powered systems.
• DC-DC converters.
• Battery protection circuits.
• Push-pull drivers.

Features:

• Complementary N-Channel and P-Channel MOSFETs.
• Low on-resistance (RDS(on)) to minimize conduction losses.
• Fast switching speed for high-frequency operation.
• Low gate charge (Qg) for efficient driving.
• Surface-mount package for efficient PCB assembly.
• RoHS compliant.

Benefits:

• Increased power conversion efficiency due to reduced conduction and switching losses.
• Improved thermal performance.
• Reduced component count and board space.
• Enhanced system reliability.
• Simplified design and layout.

Additional Details:

The FDS9945NL typically features a drain-source voltage (VDS) rating of 20V for both N and P channel MOSFETS and a continuous drain current (ID) rating that varies depending on the operating temperature and mounting conditions. The RDS(on) is low for both channels, contributing to lower power dissipation. The device is packaged in a SO-8 package. The gate threshold voltage (VGS(th)) is specified to ensure proper turn-on and turn-off characteristics. The device's thermal resistance characteristics are also important for thermal management in power applications. This complementary MOSFET offers designers a compact and efficient solution for a variety of power switching applications. Its design is tailored to improve power density and efficiency in modern electronic systems.
