Same model may have multiple batches, images only for reference.

IRLM110ATF

Name: IRLM110ATF
Brand: Fairchild/ON Semiconductor
SKU: 462749
Availability: InStock
Rating: 4.93 (5 reviews)

Get a Quote

Part No	IRLM110ATF
Manufacturer	Fairchild/ON Semiconductor
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET N-CH 100V 1.5A SOT-223
Datasheet	IRLM110ATF Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Fairchild/ON Semiconductor
Packaging	Reel - TR
Status	Obsolete(EOL)
Polarity	N-Channel
Technology	MOSFET
Drain-Source Breakdown Voltage	100V
Continuous Drain Current at 25°C	1.5A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	5V
Gate-Source Threshold Voltage	2V @ 250μA
Max Gate Charge	8nC @ 5V
Max Input Capacitance	235pF @ 25V
Maximum Gate-Source Voltage	±20V
Power Dissipation (Max)	2.2W (Tc)
Maximum Rds On at Id,Vgs	440 mOhm @ 750mA, 5V
Temperature Range - Operating	-55°C to 150°C (TJ)
Mounting	SMD (SMT)
Case / Package	SOT-223-4
Dimension	TO-261-4, TO-261AA
Win Source Part Number	1047568-IRLM110ATF
Family Name	IRLM110A
Introduction Date	November 28, 2001
ECCN	EAR99
Halogen Free	Compliant
Estimated EOL Date	Obsolete
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Application Field	Used in Power Management, Motor Drive & Control, Audio
Ultra Librarian 3D Model	Ultra Librarian IRLM110ATF CAD Model

Alternative Products

Description

The Fairchild/ON Semiconductor IRLM110ATF MOSFET is a N-channel polarity transistor with a maximum drain-source breakdown voltage of 100V and a continuous drain current of 1.5A @ 25°C.

Drain-Source Breakdown Voltage: 100V
Continuous Drain Current: 1.5A @ 25°C
Package: SOT-223-4
Gate-Source Threshold Voltage: 2V @ 250μA
Maximum Gate Charge: 8nC @ 5V
Maximum Rds On @ Id,Vgs: 440 mOhm @ 750mA and 5V
Packaging: Reel
Compliance: Halogen-free regulations
Market Status: Common-used part, popular with high demand
