MM74HC14MX

Name: MM74HC14MX
Brand: Fairchild/ON Semiconductor
SKU: 234629
Availability: InStock
Rating: 4.85 (48 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	MM74HC14MX
Manufacturer	Fairchild/ON Semiconductor
Catalog	Logic - Gates and Inverters
Description	IC TRIGGER HEX INVERT 14-SOIC
Datasheet	MM74HC14MX Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Integrated Circuits
Manufacturer	Fairchild/ON Semiconductor
Packaging	Reel - TR
Status	Active
Logic Type	Inverter
Number of Circuits	6
Number of Inputs	6
Features	Schmitt Trigger
Supply Voltage - Operating	2 V to 6 V
Current - Quiescent (Max)	2μA
Current - Output High, Low	5.2mA, 5.2mA
Logic Level - Low	0.3 V to 1.2 V
Logic Level - High	1.5 V to 4.2 V
Max Propagation Delay @ V, Max CL	21ns @ 6V, 50pF
Temperature Range - Operating	-55°C to 125°C
Mounting	SMD (SMT)
Case / Package	14-SOIC
Dimension	14-SOIC (0.154", 3.90mm Width)
Win Source Part Number	125318-MM74HC14MX
Family Name	MM74HC14
Introduction Date	January 12, 1999
ECCN	EAR99
Country of Origin	Israel
Halogen Free	Compliant
Estimated EOL Date	2025
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Application Field	Used in Signal Processing, Industrial
Quantity per package	2,500
Ultra Librarian 3D Model	Ultra Librarian MM74HC14MX CAD Model

Alternative Products

Description

The MM74HC14MX from Fairchild/ON Semiconductor is a Schmitt trigger inverter with six circuits.

Mounting: SMD (SMT)
Package: 14-SOIC
Supply Voltage: 2 V to 6 V
Maximum Propagation Delay: 21ns @ 6V, 50pF
Temperature Range: -55°C to 125°C
Status: Active
Applications: Signal processing and industrial
