SG6859ATZ Fairchild/ON Semiconductor SG6859ATZ Real Image
Same model may have multiple batches, images only for reference.
SG6859ATZ Fairchild/ON Semiconductor SG6859ATZ Real Image
SG6859ATZ Fairchild/ON Semiconductor SG6859ATZ Real Image
Same model may have multiple batches, images only for reference.

SG6859ATZ

Part No SG6859ATZ
Manufacturer Fairchild/ON Semiconductor
Catalog PMIC - AC DC Converters, Offline Switchers
Description IC OFFLINE SWITCH SUPERSOT-6 / Converter Offline Topology 20kHz ~ 70kHz SuperSOT?-6
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits (ICs) - Power Management (PMIC) - AC DC Converters, Offline Switches
Mfr Fairchild/ON Semiconductor
Package Bulk
Product Status Active
Output Isolation Isolated
Voltage - Supply (Vcc/Vdd) 9.5V ~ 22V
Frequency - Switching 20kHz ~ 70kHz
Package / Case SOT-23-6 Thin, TSOT-23-6
Supplier Device Package SuperSOT™-6
Mounting Type Surface Mount
Base Product Number SG6859
Standard Package 1 pcs
HTSUS 0000.00.0000
Win Source Part Number 319799-SG6859ATZ
Ultra Librarian 3D Model Ultra Librarian SG6859ATZ CAD Model

Description

The SG6859ATZ is an offline AC-DC converter integrated circuit (IC) designed for power management applications.

  • Package: Compact SOT-23-6 Thin
  • Mounting: Surface mount
  • Feature: Output isolation
  • Voltage Supply Range: 9.5V to 22V
  • Switching Frequency: 20kHz to 70kHz
  • Solution: Reliable and high-performance for AC-DC power conversion
  • Benefits: Ease of integration and space-saving
  • Status: Active
  • Manufacturer: Fairchild/ON Semiconductor
