The BZY97C180 is a Zener diode manufactured by Galaxy Semi-Conductor Holdings Limited. It is designed to provide a stable reference voltage of 180V, making it suitable for voltage regulation, overvoltage protection, and voltage clipping applications.

Applications:

• Voltage Regulation: Maintains a constant output voltage in power supplies and other electronic circuits.
• Overvoltage Protection: Protects sensitive components from voltage spikes and surges.
• Voltage Clipping: Limits the voltage to a specific level to prevent damage to connected circuits.
• Reference Voltage Source: Provides a stable voltage reference for measurement and control circuits.
• Transient Voltage Suppression: Absorbs energy from transient voltage events to protect downstream components.

Features:

• Precise Zener Voltage: Provides a stable and accurate 180V reference voltage.
• Low Dynamic Impedance: Ensures stable voltage regulation with minimal voltage change over varying current.
• High Surge Current Capability: Withstands high current surges without damage.
• Glass Passivated Junction: Offers high reliability and stability.
• Axial Lead Package: Facilitates easy mounting and soldering.

Benefits:

• Stable Voltage Reference: Ensures accurate and reliable voltage regulation in electronic circuits.
• Enhanced Protection: Provides robust overvoltage protection, safeguarding sensitive components.
• Improved Reliability: Glass passivated junction enhances long-term stability and performance.
• Simple Integration: Axial lead package allows for easy installation and connection in various circuit designs.

Additional Details:

The BZY97C180 typically comes in an axial lead package. Key specifications include a Zener voltage of 180V, a power dissipation of typically 1.5W, and a surge current capability to handle transient voltage spikes. It is commonly used in power supplies, telecommunications equipment, and industrial control systems where a stable and reliable voltage reference is required.
