BSP171PH6327XTSA1 Real Image BSP171PH6327XTSA1 Real Image1 BSP171PH6327XTSA1 Real Image2
Same model may have multiple batches, images only for reference.
BSP171PH6327XTSA1 Real Image BSP171PH6327XTSA1 Real Image1 BSP171PH6327XTSA1 Real Image2
BSP171PH6327XTSA1 Real Image BSP171PH6327XTSA1 Real Image1 BSP171PH6327XTSA1 Real Image2
Same model may have multiple batches, images only for reference.

BSP171PH6327XTSA1

Part No BSP171PH6327XTSA1
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET P-CH 60V 1.9A SOT223
Datasheet
BSP171PH6327XTSA1 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Reel - TR
Status Active
Polarity P-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 60V
Continuous Drain Current at 25°C 1.9A (Ta)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Gate-Source Threshold Voltage 2V @ 460μA
Max Gate Charge 20nC @ 10V
Max Input Capacitance 460pF @ 25V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 1.8W (Ta)
Maximum Rds On at Id,Vgs 300 mOhm @ 1.9A, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package PG-SOT223-4
Dimension TO-261-4, TO-261AA
Win Source Part Number 103116-BSP171PH6327XTSA1
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian BSP171PH6327XTSA1 CAD Model

Description

Product Description of BSP171PH6327XTSA1

The BSP171PH6327XTSA1 is a high-efficiency P-channel MOSFET, featuring low on-state resistance and fast switching capabilities. It is ideally suited for applications that require precise power control and compact component size.

Features and Benefits

  • Enhanced Thermal Performance
  • SOT-223 Package for easy integration
  • Low Threshold Voltage for efficient operations
  • Fast Switching

Applications

  • Load Switches
  • Power Management Circuits
  • Battery Charging Systems
  • Inverters

Additional Details: With its superior performance metrics, the BSP171PH6327XTSA1 facilitates high-efficiency solutions in cutting-edge electronic designs.
