Same model may have multiple batches, images only for reference.

IPB200N15N3G

Name: IPB200N15N3G
Brand: Infineon Technologies
SKU: 158271
Availability: InStock
Rating: 4.93 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	IPB200N15N3G
Manufacturer	Infineon Technologies
Catalog	Transistors - FETs, MOSFETs - RF
Description	IPB200N15 - 12V-300V N-CHANNEL P
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Discrete Semiconductor Products - Transistors - FETs, MOSFETs - Single FETs, MOSFETs
Mfr	Infineon Technologies
Series	OptiMOS™ 3
Package	Bulk
Product Status	Active
FET Type	N-Channel
Technology	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)	150 V
Current - Continuous Drain (Id) @ 25°C	50A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	8V, 10V
Rds On (Max) @ Id, Vgs	20mOhm @ 50A, 10V
Vgs(th) (Max) @ Id	4V @ 90µA
Gate Charge (Qg) (Max) @ Vgs	31 nC @ 10 V
Vgs (Max)	±20V
Input Capacitance (Ciss) (Max) @ Vds	1820 pF @ 75 V
Power Dissipation (Max)	150W (Tc)
Temperature Range - Operating	-55°C ~ 175°C (TJ)
Mounting Type	Surface Mount
Supplier Device Package	PG-TO263-3-2
Package / Case	TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
Standard Package	1 pcs
ECCN	EAR99
HTSUS	8542.39.0001
Win Source Part Number	158271-IPB200N15N3G
Ultra Librarian 3D Model	Ultra Librarian IPB200N15N3G CAD Model

Alternative Products

Description

The IPB200N15N3G is a N-Channel MOSFET transistor from Infineon Technologies.

Series: OptiMOS™ 3
Drain to Source Voltage (Vdss): 150V
Continuous Drain Current (Id) @ 25°C: 50A
On-Resistance (Rds On): 20mOhm @ 50A and 10V
Gate Threshold Voltage (Vgs(th)): 4V @ 90µA
Application: High power applications
Suitable for: Power supplies, motor control, and automotive applications
