IPD135N03LG Infineon Technologies IPD135N03LG real image207
Same model may have multiple batches, images only for reference.
IPD135N03LG Infineon Technologies IPD135N03LG real image207
IPD135N03LG Infineon Technologies IPD135N03LG real image207
Same model may have multiple batches, images only for reference.

IPD135N03LG

Part No IPD135N03LG
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description OPTLMOS N-CHANNEL POWER MOSFET
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Transistors - FETs, MOSFETs - Single FETs, MOSFETs
Mfr Infineon Technologies
Series CoolMOS™
Package Bulk
Product Status Active
FET Type N-Channel
Technology MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss) 30 V
Current - Continuous Drain (Id) @ 25°C 30A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Rds On (Max) @ Id, Vgs 13.5mOhm @ 30A, 10V
Vgs(th) (Max) @ Id 2.2V @ 250µA
Gate Charge (Qg) (Max) @ Vgs 10 nC @ 10 V
Vgs (Max) ±20V
Input Capacitance (Ciss) (Max) @ Vds 1000 pF @ 15 V
Power Dissipation (Max) 31W (Tc)
Temperature Range - Operating -55°C ~ 175°C (TJ)
Mounting Type Surface Mount
Supplier Device Package PG-TO252-3-11
Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
Standard Package 1 pcs
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 158359-IPD135N03LG
Ultra Librarian 3D Model Ultra Librarian IPD135N03LG CAD Model

Description

The 158359-IPD135N03LG is a N-channel MOSFET transistor from the CoolMOS™ series.

  • Drain to Source Voltage (Vdss): 30V
  • Continuous Drain Current (Id): 30A @ 25°C
  • Maximum On-Resistance (Rds On): 13.5mOhm @ 30A and 10V gate-source voltage (Vgs)
  • Gate-Source Threshold Voltage (Vgs(th)): 2.2V @ 250μA
  • Maximum Power Dissipation: 31W
  • Mounting: Surface mountable
  • Package: TO-252-3, DPak
  • Gate Charge (Qg): 10nC @ 10V gate-source voltage
  • Input Capacitance (Ciss): 1000pF @ 15V drain-source voltage (Vds)
  • Operating Temperature Range: -55°C to 175°C (TJ)
  • Status: Active
  • Manufacturer: Infineon Technologies
