Same model may have multiple batches, images only for reference.

IPW65R041CFD

Name: IPW65R041CFD
Brand: Infineon Technologies
SKU: 158736
Availability: InStock
Rating: 4.85 (48 reviews)

Get a Quote

Part No	IPW65R041CFD
Manufacturer	Infineon Technologies
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET N CH 650V 68.5A PG-TO247
Datasheet	IPW65R041CFD Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Infineon Technologies
Packaging	Tube/Rail
Status	Active
Polarity	N-Channel
Technology	MOSFET
Drain-Source Breakdown Voltage	650V
Continuous Drain Current at 25°C	68.5A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	10V
Gate-Source Threshold Voltage	4.5V @ 3.3mA
Max Gate Charge	300nC @ 10V
Max Input Capacitance	8400pF @ 100V
Maximum Gate-Source Voltage	±20V
Power Dissipation (Max)	500W (Tc)
Maximum Rds On at Id,Vgs	41 mOhm @ 33.1A, 10V
Temperature Range - Operating	-55°C to 150°C (TJ)
Mounting	Through Hole
Case / Package	PG-TO247-3
Dimension	TO-247-3
Win Source Part Number	085860-IPW65R041CFD
Family Name	IPW65R041CFD
Introduction Date	March 07, 2008
ECCN	EAR99
Halogen Free	Compliant
Estimated EOL Date	2026
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Sufficient
Ultra Librarian 3D Model	Ultra Librarian IPW65R041CFD CAD Model

Alternative Products

Description

The Infineon Technologies IPW65R041CFD is a MOSFET integrated circuit (IC) designed for use in discrete semiconductor products.

Supply and Demand Status: Sufficient
Package: PG-TO247-3
Drain-Source Breakdown Voltage: 650V
Continuous Drain Current: 68.5A (Tc)
Gate-Source Threshold Voltage: 4.5V @ 3.3mA
Maximum Gate Charge: 300nC @ 10V
Maximum Input Capacitance: 8400pF @ 100V
Maximum Rds On: 41 mOhm @ Id,Vgs is 33.1A, 10V
