IPW65R080CFD Infineon Technologies IPW65R080CFD real image
Same model may have multiple batches, images only for reference.
IPW65R080CFD Infineon Technologies IPW65R080CFD real image
IPW65R080CFD Infineon Technologies IPW65R080CFD real image
Same model may have multiple batches, images only for reference.

IPW65R080CFD

Part No IPW65R080CFD
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 700V 43.3A TO247
Datasheet
IPW65R080CFD Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Tube/Rail
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 700V
Continuous Drain Current at 25°C 43.3A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Gate-Source Threshold Voltage 4.5V @ 1.76mA
Max Gate Charge 170nC @ 10V
Max Input Capacitance 5030pF @ 100V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 391W (Tc)
Maximum Rds On at Id,Vgs 80 mOhm @ 17.6A, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting Through Hole
Case / Package PG-TO247-3
Dimension TO-247-3
Win Source Part Number 017332-IPW65R080CFD
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Application Field Used in Communications & Networking, Computers & Computer Peripherals, Alternative Energy, LED Lighting
Ultra Librarian 3D Model Ultra Librarian IPW65R080CFD CAD Model

Description

The Infineon Technologies 017332-IPW65R080CFD is a N-Channel MOSFET with a Drain-Source Breakdown Voltage of 700V.

  • Continuous Drain Current: 43.3A (Tc) @ 25°C
  • Maximum Rds On: 80 mOhm @ 17.6A, 10V
  • Maximum Gate-Source Voltage: ±20V
  • Package: PG-TO247-3
  • Suitable for: Discrete Semiconductor Products
  • Operating Temperature Range: -55°C to 150°C (TJ)
  • Power Dissipation: 391W (Tc)
  • Supply and Demand Status: Limited
  • Commonly used in: Communications & Networking, Computers & Computer Peripherals, Alternative Energy, LED Lighting
