Same model may have multiple batches, images only for reference.
IRF2807PBF real image239
Same model may have multiple batches, images only for reference.

IRF2807PBF

Part No IRF2807PBF
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description Trans MOSFET N-CH Si 75V 82A 3-Pin(3+Tab) TO-220AB Tube / MOSFET N-CH 75V 82A TO-220AB
Datasheet
IRF2807PBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Tube/Rail
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 75V
Continuous Drain Current at 25°C 82A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Gate-Source Threshold Voltage 4V @ 250μA
Max Gate Charge 160nC @ 10V
Max Input Capacitance 3820pF @ 25V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 230W (Tc)
Maximum Rds On at Id,Vgs 13 mOhm @ 43A, 10V
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting Through Hole
Case / Package TO-220AB
Dimension TO-220-3
Win Source Part Number 092981-IRF2807PBF
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Family Name IRF2807
Introduction Date February 02, 2004
ECCN EAR99
Country of Origin Republic of Korea
Estimated EOL Date 2029
Ultra Librarian 3D Model Ultra Librarian IRF2807PBF CAD Model

Description

The Infineon Technologies IRF2807PBF is a N-Channel MOSFET transistor designed for use in a variety of applications.

  • Drain-Source Breakdown Voltage: 75V
  • Continuous Drain Current: 82A @ 25°C
  • Maximum Power Dissipation: 230W (Tc)
  • Gate-Source Threshold Voltage: 4V @ 250μA
  • Maximum Gate Charge: 160nC @ 10V
  • Maximum Rds On: 13 mOhm @ 43A, 10V
  • Package: TO-220AB
  • Maximum Gate-Source Voltage: ±20V
  • Product Family: IRF2807
  • Category: Discrete Semiconductor Products
  • ECCN: EAR99 compliant
  • Estimated EOL Date: 2029
  • Status: common-used part with high popularity and sufficient supply and demand status
