IRF7309TRPBF Infineon Technologies IRF7309TRPBF real image
Same model may have multiple batches, images only for reference.
IRF7309TRPBF Infineon Technologies IRF7309TRPBF real image
IRF7309TRPBF Infineon Technologies IRF7309TRPBF real image
Same model may have multiple batches, images only for reference.

IRF7309TRPBF

Part No IRF7309TRPBF
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N/P-CH 30V 4A/3A 8SOIC
Datasheet
IRF7309TRPBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Reel - TR
Status Active
FET Type N and P-Channel
FET Feature Standard
Drain-Source Breakdown Voltage 30V
Continuous Drain Current at 25°C 4A, 3A
Maximum Rds On at Id,Vgs 50 mOhm @ 2.4A, 10V
Gate-Source Threshold Voltage 1V @ 250μA
Max Gate Charge 25nC @ 4.5V
Max Input Capacitance 520pF @ 15V
Maximum Power Dissipation 1.4W
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 8-SO
Win Source Part Number 017498-IRF7309TRPBF
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian IRF7309TRPBF CAD Model

Description

The Infineon Technologies IRF7309TRPBF is an N and P-channel SMD (SMT) mounted FET.

  • Standard FET: maximum power dissipation of 1.4W
  • Drain-Source Breakdown Voltage: 30V
  • Continuous Drain Current: 4A, 3A
  • Gate-Source Threshold Voltage: 1V @ 250μA
  • Maximum Rds On at Id,Vgs: 50 mOhm @ 2.4A, 10V
  • Suitable for: use in a variety of electronic devices
  • Common-used part: true
  • Supply and Demand Status: sufficient
