IRF7343TRPBF Infineon Technologies IRF7343TRPBF real image280 IRF7343TRPBF real image281 IRF7343TRPBF Real Image1 IRF7343TRPBF Real Image2 IRF7343TRPBF Real Image3
Same model may have multiple batches, images only for reference.
IRF7343TRPBF Infineon Technologies IRF7343TRPBF real image280 IRF7343TRPBF real image281 IRF7343TRPBF Real Image1 IRF7343TRPBF Real Image2 IRF7343TRPBF Real Image3
IRF7343TRPBF Infineon Technologies IRF7343TRPBF real image280 IRF7343TRPBF real image281 IRF7343TRPBF Real Image1 IRF7343TRPBF Real Image2 IRF7343TRPBF Real Image3
Same model may have multiple batches, images only for reference.

IRF7343TRPBF

Part No IRF7343TRPBF
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N/P-CH 55V 8-SOIC
Datasheet
IRF7343TRPBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Reel - TR
Status Active
FET Type N and P-Channel
FET Feature Standard
Drain-Source Breakdown Voltage 55V
Continuous Drain Current at 25°C 4.7A, 3.4A
Maximum Rds On at Id,Vgs 50 mOhm @ 4.7A, 10V
Gate-Source Threshold Voltage 1V @ 250μA
Max Gate Charge 36nC @ 10V
Max Input Capacitance 740pF @ 25V
Maximum Power Dissipation 2W
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 8-SO
Win Source Part Number 017513-IRF7343TRPBF
Family Name IRF7343
Introduction Date February 24, 1999
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2024
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian IRF7343TRPBF CAD Model

Description

The Infineon Technologies 017513-IRF7343TRPBF is a standard N and P-Channel MOSFET that is commonly used in various electronic applications.

  • Drain-Source Breakdown Voltage: 55V
  • Continuous Drain Current: 4.7A, 3.4A @ 25°C
  • Maximum Rds On: 50 mOhm @ 4.7A, 10V
  • Gate-Source Threshold Voltage: 1V @ 250μA
  • Maximum Gate Charge: 36nC @ 10V
  • Maximum Input Capacitance: 740pF @ 25V
  • Package: 8-SO
  • Mounting Technology: SMD (SMT) technology
  • Supply: sufficient
