IRF7821PBF

Name: IRF7821PBF
Brand: Infineon Technologies
SKU: 160066
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	IRF7821PBF
Manufacturer	Infineon Technologies
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET N-CH 30V 13.6A 8-SOIC
Datasheet	IRF7821PBF Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Infineon Technologies
Packaging	Tube/Rail
Status	Not For New Designs
Polarity	N-Channel
Technology	MOSFET
Drain-Source Breakdown Voltage	30V
Continuous Drain Current at 25°C	13.6A (Ta)
Drive Voltage (Max Rds On, Min Rds On)	4.5V, 10V
Gate-Source Threshold Voltage	1V @ 250μA
Max Gate Charge	14nC @ 4.5V
Max Input Capacitance	1010pF @ 15V
Maximum Gate-Source Voltage	±20V
Power Dissipation (Max)	2.5W (Ta)
Maximum Rds On at Id,Vgs	9.1 mOhm @ 13A, 10V
Temperature Range - Operating	-55°C to 155°C (TJ)
Mounting	SMD (SMT)
Case / Package	8-SO
Dimension	8-SOIC (0.154", 3.90mm Width)
Win Source Part Number	001954-IRF7821PBF
Popularity	Medium
Supply and Demand Status	Balance
Ultra Librarian 3D Model	Ultra Librarian IRF7821PBF CAD Model

Alternative Products

Description

The Infineon Technologies 167246 MOSFET is a N-Channel polarity component used in power management, industrial applications.

Polarity: N-Channel
Drain-Source Breakdown Voltage: 30V
Continuous Drain Current: 13.6A (Ta) @ 25°C
Maximum Rds On @ Id,Vgs: 9.1 mOhm @ 13A, 10V
Drive Voltage: 4.5V, 10V
Status: Not for new designs
Temperature Range: -55°C to 155°C (TJ)
Package: 8-SO
Dimension: 8-SOIC (0.154", 3.90mm Width)
Maximum Gate-Source Voltage: ±20V
Maximum Gate Charge: 14nC @ 4.5V
Maximum Input Capacitance: 1010pF @ 15V
Supply and Demand Status: Balanced
