Same model may have multiple batches, images only for reference.

IRF8736PBF

Name: IRF8736PBF
Brand: Infineon Technologies
SKU: 160147
Availability: InStock
Rating: 4.91 (146 reviews)

Get a Quote

Part No	IRF8736PBF
Manufacturer	Infineon Technologies
Catalog	Transistors - FETs, MOSFETs - RF
Description	Trans MOSFET N-CH 30V 18A 8-Pin SOIC Tube / MOSFET N-CH 30V 18A 8-SOIC
Datasheet	IRF8736PBF Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Infineon Technologies
Packaging	Tube/Rail
Status	Not For New Designs
Polarity	N-Channel
Technology	MOSFET
Drain-Source Breakdown Voltage	30V
Continuous Drain Current at 25°C	18A (Ta)
Drive Voltage (Max Rds On, Min Rds On)	4.5V, 10V
Gate-Source Threshold Voltage	2.35V @ 50μA
Max Gate Charge	26nC @ 4.5V
Max Input Capacitance	2315pF @ 15V
Maximum Gate-Source Voltage	±20V
Power Dissipation (Max)	2.5W (Ta)
Maximum Rds On at Id,Vgs	4.8 mOhm @ 18A, 10V
Temperature Range - Operating	-55°C to 150°C (TJ)
Mounting	SMD (SMT)
Case / Package	8-SO
Dimension	8-SOIC (0.154", 3.90mm Width)
Win Source Part Number	205323-IRF8736PBF
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Limited
Family Name	IRF8736
Introduction Date	August 01, 2007
ECCN	EAR99
Country of Origin	Austria, China, Malaysia, Philippines, Thailand
Halogen Free	Compliant
Estimated EOL Date	Obsolete / End of life
Ultra Librarian 3D Model	Ultra Librarian IRF8736PBF CAD Model

Alternative Products

Description

The Infineon Technologies IRF8736PBF is a MOSFET transistor designed for use in various electronic applications.

Drain-Source Breakdown Voltage: 30V
Continuous Drain Current: 18A @ 25°C
