IRF9389TRPBF Real Image IRF9389TRPBF real image308 IRF9389TRPBF Real Image1 IRF9389TRPBF Real Image2 IRF9389TRPBF Real Image3
Same model may have multiple batches, images only for reference.
IRF9389TRPBF Real Image IRF9389TRPBF real image308 IRF9389TRPBF Real Image1 IRF9389TRPBF Real Image2 IRF9389TRPBF Real Image3
IRF9389TRPBF Real Image IRF9389TRPBF real image308 IRF9389TRPBF Real Image1 IRF9389TRPBF Real Image2 IRF9389TRPBF Real Image3
Same model may have multiple batches, images only for reference.

IRF9389TRPBF

Part No IRF9389TRPBF
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N/P-CH 30V 6.8A/4.6A 8-SO
Datasheet
IRF9389TRPBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Reel - TR
Status Active
FET Type N and P-Channel
FET Feature Logic Level Gate
Drain-Source Breakdown Voltage 30V
Continuous Drain Current at 25°C 6.8A, 4.6A
Maximum Rds On at Id,Vgs 27 mOhm @ 6.8A, 10V
Gate-Source Threshold Voltage 2.3V @ 10μA
Max Gate Charge 14nC @ 10V
Max Input Capacitance 398pF @ 15V
Maximum Power Dissipation 2W
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 8-SO
Win Source Part Number 135291-IRF9389TRPBF
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian IRF9389TRPBF CAD Model

Description

The Infineon Technologies IRF9389TRPBF is a N and P-Channel FET type discrete semiconductor product with a Logic Level Gate feature.

  • Package Type: 8-SO
  • Drain-Source Breakdown Voltage: 30V
  • Continuous Drain Current at 25°C: 6.8A, 4.6A
  • Gate-Source Threshold Voltage: 2.3V @ 10μA
  • Maximum Rds On at Id, Vgs: 27 mOhm @ 6.8A, 10V
  • Temperature Range: -55°C to 150°C (TJ)
  • Maximum Power Dissipation: 2W
