IRF9540NPBF

Name: IRF9540NPBF
Brand: Infineon Technologies
SKU: 160197
Availability: InStock
Rating: 4.91 (349 reviews)

Get a Quote

Part No	IRF9540NPBF
Manufacturer	Infineon Technologies
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET P-CH 100V 23A TO-220AB
Datasheet	IRF9540NPBF Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Infineon Technologies
Packaging	Tube/Rail
Status	Active
Polarity	P-Channel
Technology	MOSFET
Drain-Source Breakdown Voltage	100V
Continuous Drain Current at 25°C	23A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	10V
Gate-Source Threshold Voltage	4V @ 250μA
Max Gate Charge	97nC @ 10V
Max Input Capacitance	1300pF @ 25V
Maximum Gate-Source Voltage	±20V
Power Dissipation (Max)	140W (Tc)
Maximum Rds On at Id,Vgs	117 mOhm @ 11A, 10V
Temperature Range - Operating	-55°C to 150°C (TJ)
Mounting	Through Hole
Case / Package	TO-220AB
Dimension	TO-220-3
Win Source Part Number	017560-IRF9540NPBF
Family Name	IRF9540
Introduction Date	January 23, 2004
ECCN	EAR99
Country of Origin	China
Estimated EOL Date	2024
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Sufficient
Ultra Librarian 3D Model	Ultra Librarian IRF9540NPBF CAD Model

Alternative Products

Description

The Infineon Technologies IRF9540NPBF is a P-channel MOSFET transistor that is ideal for use in various electronic applications.

Drain-Source Breakdown Voltage: 100V
Continuous Drain Current: 23A @ 25°C
Maximum Rds on @ Id,Vgs: 117 mOhm @ 11A, 10V
Maximum Gate-Source Voltage: ±20V
Gate-Source Threshold Voltage: 4V @ 250μA
Maximum Power Dissipation: 140W (Tc)
Package: TO-220AB
Suitable for: Discrete semiconductor products
