IRF9956TRPBF Real Image IRF9956TRPBF Real Image
Same model may have multiple batches, images only for reference.
IRF9956TRPBF Real Image IRF9956TRPBF Real Image
IRF9956TRPBF Real Image IRF9956TRPBF Real Image
Same model may have multiple batches, images only for reference.

IRF9956TRPBF

Part No IRF9956TRPBF
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET 2N-CH 30V 3.5A 8-SOIC
Datasheet
IRF9956TRPBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Reel - TR
Status Active
FET Type 2 N-Channel (Dual)
FET Feature Logic Level Gate
Drain-Source Breakdown Voltage 30V
Continuous Drain Current at 25°C 3.5A
Maximum Rds On at Id,Vgs 100 mOhm @ 2.2A, 10V
Gate-Source Threshold Voltage 1V @ 250μA
Max Gate Charge 14nC @ 10V
Max Input Capacitance 190pF @ 15V
Maximum Power Dissipation 2W
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 8-SO
Win Source Part Number 113420-IRF9956TRPBF
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian IRF9956TRPBF CAD Model

Description

The Infineon Technologies 113420-IRF9956TRPBF is a dual N-channel logic level gate FET.

  • Drain-Source Breakdown Voltage: 30V
  • Continuous Drain Current at 25°C: 3.5A @ 25°C
  • Maximum Power Dissipation: 2W
  • Packaging: reel - TR
  • Temperature Range: -55°C to 150°C (TJ)
  • Case/Package: 8-SO
  • Mounting: SMD (SMT)
  • Gate-Source Threshold Voltage: 1V @ 250μA
  • Maximum Rds On at Id,Vgs: 100 mOhm @ 2.2A, 10V
