Same model may have multiple batches, images only for reference.

IRF9Z34NSTRLPBF

Name: IRF9Z34NSTRLPBF
Brand: Infineon Technologies
SKU: 160233
Availability: InStock
Rating: 4.85 (48 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	IRF9Z34NSTRLPBF
Manufacturer	Infineon Technologies
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET P-CH 55V 19A D2PAK / Trans MOSFET P-CH Si 55V 19A 3-Pin(2+Tab) D2PAK T/R
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Infineon Technologies
Packaging	Reel - TR
Status	Active
Polarity	P-Channel
Technology	MOSFET
Drain-Source Breakdown Voltage	55V
Continuous Drain Current at 25°C	19A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	10V
Gate-Source Threshold Voltage	4V @ 250μA
Max Gate Charge	35nC @ 10V
Max Input Capacitance	620pF @ 25V
Maximum Gate-Source Voltage	±20V
Power Dissipation (Max)	3.8W (Ta), 68W (Tc)
Maximum Rds On at Id,Vgs	100 mOhm @ 10A, 10V
Temperature Range - Operating	-55°C to 175°C (TJ)
Mounting	SMD (SMT)
Case / Package	D2PAK
Dimension	TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Win Source Part Number	015802-IRF9Z34NSTRLPBF
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Limited
Family Name	IRF9Z34NS
Introduction Date	August 25, 1997
ECCN	EAR99
Country of Origin	Republic of Korea, Mexico
Halogen Free	Compliant
Estimated EOL Date	2027
Ultra Librarian 3D Model	Ultra Librarian IRF9Z34NSTRLPBF CAD Model

Alternative Products

Description

The Infineon Technologies IRF9Z34NSTRLPBF is a P-channel MOSFET with a drain-source breakdown voltage of 55V and a continuous drain current of 19A at 25°C.

Package: D2PAK
Popularity: high
Supply and Demand Status: limited
Win Source Part Number: 015802-IRF9Z34NSTRLPBF
