IRFL4315TRPBF Real Image IRFL4315TRPBF real image341
Same model may have multiple batches, images only for reference.
IRFL4315TRPBF Real Image IRFL4315TRPBF real image341
IRFL4315TRPBF Real Image IRFL4315TRPBF real image341
Same model may have multiple batches, images only for reference.

IRFL4315TRPBF

Part No IRFL4315TRPBF
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description Trans MOSFET N-CH 150V 2.6A Automotive 4-Pin(3+Tab) SOT-223 T/R / MOSFET N-CH 150V 2.6A SOT223
Datasheet
IRFL4315TRPBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 150V
Continuous Drain Current at 25°C 2.6A (Ta)
Drive Voltage (Max Rds On, Min Rds On) 10V
Gate-Source Threshold Voltage 5V @ 250μA
Max Gate Charge 19nC @ 10V
Max Input Capacitance 420pF @ 25V
Maximum Gate-Source Voltage ±30V
Power Dissipation (Max) 2.8W (Ta)
Maximum Rds On at Id,Vgs 185 mOhm @ 1.6A, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package SOT-223
Dimension TO-261-4, TO-261AA
Win Source Part Number 120614-IRFL4315TRPBF
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name IRFL4315
Introduction Date June 14, 2002
ECCN EAR99
Country of Origin China, Malaysia
Halogen Free Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian IRFL4315TRPBF CAD Model

Description

The Infineon Technologies MOSFET is a N-Channel polarity power transistor designed for discrete semiconductor products.

  • Power Dissipation: 2.8W (Ta)
  • Drain-Source Breakdown Voltage: 150V
  • Continuous Drain Current at 25°C: 2.6A (Ta)
  • Gate-Source Threshold Voltage: 5V @ 250μA
  • Maximum Gate Charge: 19nC @ 10V
  • Maximum Input Capacitance: 420pF @ 25V
  • Maximum Rds On at Id,Vgs: 185 mOhm @ 1.6A, 10V
  • Package: SOT-223
  • Dimension: TO-261-4, TO-261AA
  • Mounting: SMD (SMT)
  • Status: active
  • Popularity: high
  • Supply and Demand Status: balance
