IRL1004STRL Infineon Technologies IRL1004STRL Real Image IRL1004STRL label picture 2 IRL1004STRL real image
Same model may have multiple batches, images only for reference.
IRL1004STRL Infineon Technologies IRL1004STRL Real Image IRL1004STRL label picture 2 IRL1004STRL real image
IRL1004STRL Infineon Technologies IRL1004STRL Real Image IRL1004STRL label picture 2 IRL1004STRL real image
Same model may have multiple batches, images only for reference.

IRL1004STRL

Part No IRL1004STRL
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 40V 130A D2PAK
Datasheet
IRL1004STRL Datasheet
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Reel - TR
Status Obsolete(EOL)
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 40V
Continuous Drain Current at 25°C 130A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Gate-Source Threshold Voltage 1V @ 250μA
Max Gate Charge 100nC @ 4.5V
Max Input Capacitance 5330pF @ 25V
Maximum Gate-Source Voltage ±16V
Power Dissipation (Max) 3.8W (Ta), 200W (Tc)
Maximum Rds On at Id,Vgs 6.5 mOhm @ 78A, 10V
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting SMD (SMT)
Case / Package D2PAK
Dimension TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Win Source Part Number 1047416-IRL1004STRL
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian IRL1004STRL CAD Model

Description

The Infineon Technologies 439030 is a high-performance N-channel MOSFET designed for use in various electronic applications.

  • Case/Package: TO-263-3, D2Pak
  • Power Dissipation: 3.8W (Ta), 200W (Tc)
  • Drain-Source Breakdown Voltage: 40V
  • Continuous Drain Current: 130A (Tc) @ 25°C
  • Gate-Source Threshold Voltage: 1V @ 250μA
  • Maximum Gate Charge: 100nC @ 4.5V
  • Maximum Rds On: 6.5 mOhm @ 78A, 10V
  • Lifecycle Status: Obsolete(EOL)
  • Operating Temperature: -55°C to 175°C (TJ)
