IRLML0060TRPBF Real Image IRLML0060TRPBF real image383 IRLML0060TRPBF real image384 IRLML0060TRPBF Real Image
Same model may have multiple batches, images only for reference.
IRLML0060TRPBF Real Image IRLML0060TRPBF real image383 IRLML0060TRPBF real image384 IRLML0060TRPBF Real Image
IRLML0060TRPBF Real Image IRLML0060TRPBF real image383 IRLML0060TRPBF real image384 IRLML0060TRPBF Real Image
Same model may have multiple batches, images only for reference.

IRLML0060TRPBF

Part No IRLML0060TRPBF
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 60V 2.7A SOT-23-3
Datasheet
IRLML0060TRPBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 60V
Continuous Drain Current at 25°C 2.7A (Ta)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Gate-Source Threshold Voltage 2.5V @ 25μA
Max Gate Charge 2.5nC @ 4.5V
Max Input Capacitance 290pF @ 25V
Maximum Gate-Source Voltage ±16V
Power Dissipation (Max) 1.25W (Ta)
Maximum Rds On at Id,Vgs 92 mOhm @ 2.7A, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package Micro3/SOT-23
Dimension TO-236-3, SC-59, SOT-23-3
Win Source Part Number 017761-IRLML0060TRPBF
Family Name IRLML0060
Introduction Date December 02, 2009
ECCN EAR99
Country of Origin Philippines
Halogen Free Compliant
Estimated EOL Date 2024
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian IRLML0060TRPBF CAD Model

Description

The Infineon Technologies IRLML0060TRPBF is an N-Channel MOSFET transistor designed for use in power management applications.

  • Drain-Source Breakdown Voltage: 60V
  • Continuous Drain Current: 2.7A @ 25°C
  • Maximum Power Dissipation: 1.25W @ Ta
  • Package: Micro3/SOT-23
  • Maximum Rds On: 92 mOhm @ 2.7A, 10V
  • Popularity: High (65%)
  • Packaging: Reel-TR
  • Mounting Type: SMD (SMT)
