Same model may have multiple batches, images only for reference.

IRLML6344TRPBF

Name: IRLML6344TRPBF
Brand: Infineon Technologies
SKU: 161517
Availability: InStock
Rating: 4.85 (241 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	IRLML6344TRPBF
Manufacturer	Infineon Technologies
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET N-CH 30V 5A SOT23
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Infineon Technologies
Packaging	Reel - TR
Status	Active
Polarity	N-Channel
Technology	MOSFET
Drain-Source Breakdown Voltage	30V
Continuous Drain Current at 25°C	5A (Ta)
Drive Voltage (Max Rds On, Min Rds On)	2.5V, 4.5V
Gate-Source Threshold Voltage	1.1V @ 10μA
Max Gate Charge	6.8nC @ 4.5V
Max Input Capacitance	650pF @ 25V
Maximum Gate-Source Voltage	±12V
Power Dissipation (Max)	1.3W (Ta)
Maximum Rds On at Id,Vgs	29 mOhm @ 5A, 4.5V
Temperature Range - Operating	-55°C to 150°C (TJ)
Mounting	SMD (SMT)
Case / Package	Micro3/SOT-23
Dimension	TO-236-3, SC-59, SOT-23-3
Win Source Part Number	095150-IRLML6344TRPBF
Family Name	IRLML6344
Introduction Date	March 04, 2004
ECCN	EAR99
Country of Origin	China
Halogen Free	Compliant
Estimated EOL Date	2025
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Ultra Librarian 3D Model	Ultra Librarian IRLML6344TRPBF CAD Model

Alternative Products

Description

The Infineon Technologies MOSFET is a N-channel polarity electronic component with a maximum power dissipation of 1.3W (Ta).

Maximum Power Dissipation: 1.3W (Ta)
Drive Voltage: 2.5V (max Rds On) and 4.5V (min Rds On)
Drain-Source Breakdown Voltage: 30V
Continuous Drain Current @ 25°C: 5A (Ta)
Gate-Source Threshold Voltage: 1.1V @ 10μA
Maximum Gate Charge: 6.8nC @ 4.5V
Maximum Input Capacitance: 650pF @ 25V
Maximum Gate-Source Voltage: ±12V
Maximum Rds On @ Id,Vgs: 29 mOhm @ 5A, 4.5V
Mounting: SMD (SMT)
Package: Micro3/SOT-23
Category: Discrete semiconductor products
