IRLML9301TRPBF

Part No IRLML9301TRPBF
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description Trans MOSFET P-CH 30V 3.6A 3-Pin SOT-23 T/R / MOSFET P-CH 30V 3.6A SOT-23-3
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Reel - TR
Status Active
Polarity P-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 30V
Continuous Drain Current at 25°C 3.6A (Ta)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Gate-Source Threshold Voltage 2.4V @ 10μA
Max Gate Charge 4.8nC @ 4.5V
Max Input Capacitance 388pF @ 25V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 1.3W (Ta)
Maximum Rds On at Id,Vgs 64 mOhm @ 3.6A, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package Micro3/SOT-23
Dimension TO-236-3, SC-59, SOT-23-3
Win Source Part Number 017776-IRLML9301TRPBF
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name IRLML9301
Introduction Date May 27, 2010
ECCN EAR99
Country of Origin Philippines, Thailand
Halogen Free Compliant
Estimated EOL Date 2029
Ultra Librarian 3D Model Ultra Librarian IRLML9301TRPBF CAD Model

Description

IRLML9301TRPBF from Infineon Technologies is listed in the Transistors - FETs, MOSFETs - RF category and is typically evaluated by engineers for compact switching or RF-related circuit designs where board space, efficiency, and supplier pedigree matter. Components in this class are often considered for portable electronics, signal control stages, low-power interface designs, and supporting functions in communication hardware. Infineon’s brand positioning makes this part relevant for teams prioritizing established semiconductor sourcing and long-term design confidence. The current lifecycle status for IRLML9301TRPBF is information not available, so designers should confirm whether the device is active, NRND, or discontinued before committing it to new programs. RoHS compliance status is also information not available in the provided data. For regulated builds, engineers and procurement teams should verify the latest environmental declarations, datasheet details, and manufacturer compliance documents before qualification or volume purchasing.
