IRLR3110ZTRPBF Real Image IRLR3110ZTRPBF Real Image1 IRLR3110ZTRPBF Real Image2
Same model may have multiple batches, images only for reference.
IRLR3110ZTRPBF Real Image IRLR3110ZTRPBF Real Image1 IRLR3110ZTRPBF Real Image2
IRLR3110ZTRPBF Real Image IRLR3110ZTRPBF Real Image1 IRLR3110ZTRPBF Real Image2
Same model may have multiple batches, images only for reference.

IRLR3110ZTRPBF

Part No IRLR3110ZTRPBF
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 100V 42A DPAK
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 100V
Continuous Drain Current at 25°C 42A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Gate-Source Threshold Voltage 2.5V @ 100μA
Max Gate Charge 48nC @ 4.5V
Max Input Capacitance 3980pF @ 25V
Maximum Gate-Source Voltage ±16V
Power Dissipation (Max) 140W (Tc)
Maximum Rds On at Id,Vgs 14 mOhm @ 38A, 10V
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting SMD (SMT)
Case / Package D-Pak
Dimension TO-252-3, DPak (2 Leads + Tab), SC-63
Win Source Part Number 017795-IRLR3110ZTRPBF
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name IRLR3110Z
Introduction Date March 09, 2006
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2024
Ultra Librarian 3D Model Ultra Librarian IRLR3110ZTRPBF CAD Model

Description

The Infineon Technologies IRLR3110ZTRPBF is an N-channel MOSFET transistor with a drain-source breakdown voltage of 100V and a maximum continuous drain current of 42A.

  • Drain-Source Breakdown Voltage: 100V
  • Maximum Continuous Drain Current: 42A
  • Maximum Rds On at Id,Vgs: 14 mOhm @ 38A, 10V
  • Gate-Source Threshold Voltage: 2.5V @ 100μA
  • Maximum Gate Charge: 48nC @ 4.5V
  • Maximum Input Capacitance: 3980pF @ 25V
  • Technology: MOSFET
  • Mounting: reel - TR
  • Status: active
  • Packaging: D-Pak packaging
  • Discrete Semiconductor Products Use: yes
