IXTV22N50P

Get a Quote

Part No	IXTV22N50P
Manufacturer	IXYS
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET N-CH 500V 22A PLUS220 / N-Channel 500 V 22A (Tc) 350W (Tc) Through Hole PLUS220
Sample
Rohs State	Need to verify
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Discrete Semiconductor Products - Transistors - FETs, MOSFETs - Single FETs, MOSFETs
Mfr	IXYS
Series	PolarHV™
Package	Tube
Product Status	Obsolete
FET Type	N-Channel
Technology	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)	500 V
Current - Continuous Drain (Id) @ 25°C	22A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	10V
Rds On (Max) @ Id, Vgs	270mOhm @ 11A, 10V
Vgs(th) (Max) @ Id	5.5V @ 250µA
Gate Charge (Qg) (Max) @ Vgs	50 nC @ 10 V
Vgs (Max)	±30V
Input Capacitance (Ciss) (Max) @ Vds	2630 pF @ 25 V
Power Dissipation (Max)	350W (Tc)
Temperature Range - Operating	-55°C ~ 150°C (TJ)
Mounting Type	Through Hole
Supplier Device Package	PLUS220
Package / Case	TO-220-3, Short Tab
Base Product Number	IXTV22
Standard Package	50
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8541.29.0095
Win Source Part Number	1346648-IXTV22N50P
Ultra Librarian 3D Model	Ultra Librarian IXTV22N50P CAD Model

Alternative Products

Description

The IXYS IXTV22N50P is an N-Channel MOSFET transistor from the PolarHV™ series of IXYS.

Package: TO-220-3, Short Tab
Drain to Source Voltage (Vdss): 500 V
Maximum Power Dissipation: 350W (Tc)
Maximum Gate-Source Voltage (Vgs): ±30V
Temperature Range: -55°C to 150°C (TJ)
Current-Continuous Drain (Id): 22A (Tc)
Maximum On-Resistance (Rds On): 270mOhm @ 11A, 10V
Gate Charge (Qg): 50 nC @ 10 V
Input Capacitance (Ciss): 2630 pF @ 25 V
Ideal for use in: applications such as power supplies, motor control, and lighting.
