Same model may have multiple batches, images only for reference.
SU9HD-25018 Real Image
Same model may have multiple batches, images only for reference.

SU9HD-25018

Part No SU9HD-25018
Manufacturer Kemet
Catalog Common Mode Chokes
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Filters>Common Mode Chokes
Mfr KEMET
Series SU
Package Tray
Filter Type Power Line
Number of Lines 2
Inductance @ Frequency 17.99 µH @ 1 kHz
Current Rating (Max) 2.5A
DC Resistance (DCR) (Max) 55mOhm
Voltage Rating - AC 250V
Temperature Range - Operating -25°C ~ 120°C
Mounting Type Through Hole
Dimension 0.669" L x 0.610" W (17.00mm x 15.50mm)
Height (Max) 0.492" (12.50mm)
Package / Case Vertical, 4 PC Pin
Base Product Number SU9HD
Other Names 399-SU9HD-25018,UALSU9HD250180
Standard Package 1,000
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8548.00.0000
Win Source Part Number 1276469-SU9HD-25018
Ultra Librarian 3D Model Ultra Librarian SU9HD-25018 CAD Model

Description

The SU9HD-25018 is a common mode choke from KEMET that has a voltage rating of 250V and a current rating of 2.5A.

  • Voltage Rating: 250V
  • Current Rating: 2.5A
  • Inductance: 17.99 µH @ 1 kHz
  • DC Resistance (DCR): 55mOhm
  • Maximum Height: 0.492" (12.50mm)
  • Package: Vertical, 4 PC pin
  • Application: Power line filtering
  • Operating Temperature: -25°C to 120°C
