SU9VF-01250 Real Image
Same model may have multiple batches, images only for reference.

SU9VF-01250

Part No SU9VF-01250
Manufacturer Kemet
Catalog Common Mode Chokes
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Filters>Common Mode Chokes
Mfr KEMET
Series SU
Package Tray
Filter Type Power Line
Number of Lines 2
Inductance @ Frequency 25 mH @ 1 kHz
Current Rating (Max) 100mA
DC Resistance (DCR) (Max) 9Ohm
Voltage Rating - AC 250V
Temperature Range - Operating -25°C ~ 120°C
Mounting Type Through Hole
Dimension 0.669" L x 0.433" W (17.00mm x 11.00mm)
Height (Max) 0.669" (17.00mm)
Package / Case Vertical, 4 PC Pin
Base Product Number SU9VF
Other Names UALSU9VF012500,399-SU9VF-01250
Standard Package 1,000
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8548.00.0000
Win Source Part Number 1276465-SU9VF-01250
Ultra Librarian 3D Model Ultra Librarian SU9VF-01250 CAD Model

Description

The SU series common mode choke from KEMET is a power line filter type with a voltage rating of 250V AC and a maximum current rating of 100mA.

  • Manufacturer: KEMET
  • Filter Type: Power Line
  • Voltage Rating: 250V AC
  • Maximum Current Rating: 100mA
  • Inductance: 25mH @ 1kHz
  • DC Resistance: 9Ohm
  • Package: Vertical, 4 PC pin type with a tray package
  • Temperature Range: -25°C to 120°C
  • Dimension: 0.669" L x 0.433" W (17.00mm x 11.00mm)
  • Choke Model: SU9VF-01250
  • Application: Filtering of power lines and noise reduction
