The LT1964ES5-BYP#TRMPBF is a high-performance, low dropout negative voltage regulator designed by Linear Technology, which is renowned for its precision electronic components. This regulator is specifically tailored for applications requiring a low noise, high power supply rejection ratio (PSRR), and a stable, negative output voltage.

Key Features

• Output Voltage: The device provides a fixed output voltage of -1.2V, which is ideal for various analog and digital circuits that require a precise negative supply voltage.
• Low Dropout Voltage: It has an impressively low dropout voltage, ensuring efficient operation even when the input-to-output voltage differential is minimal.
• High PSRR: With an excellent power supply rejection ratio, this regulator significantly minimizes noise from the input power source, thus providing a cleaner and more stable output voltage.
• Low Noise: The LT1964ES5-BYP#TRMPBF has been designed to have low output noise, making it suitable for sensitive applications such as audio equipment and precision instrumentation.
• Current Capacity: It is capable of delivering up to 200mA of output current, which is sufficient for a wide range of applications.
• Thermal Protection: The device includes thermal shutdown protection to safeguard against overheating and potential damage under high-temperature conditions.

Applications

The LT1964ES5-BYP#TRMPBF is versatile and can be used in a variety of applications, including:

• Portable Battery-Powered Devices
• Low Noise Instrumentation
• Reference Voltage Generation
• Power Supplies for Op Amps and DACs
• Audio Applications

Package and Quality

This regulator is available in a compact SOT-23 package, which is suitable for space-constrained applications. It is also part of the tape and reel packaging, denoted by the '#TRMPBF' suffix, which facilitates automated assembly processes. Linear Technology ensures high-quality and reliability for this product, making it a reliable choice for both commercial and industrial applications.
