The LTC3428EDD from Linear Technology is a versatile, high-efficiency, synchronous step-down DC/DC converter. Designed to meet the stringent power requirements of modern portable devices, this compact converter is housed in a small 10-lead DFN package with a 3mm x 3mm footprint, making it an excellent choice for space-constrained applications.
With an input voltage range of 2.5V to 5.5V, the LTC3428EDD is ideal for single-cell Li-Ion or multi-cell alkaline/NiMH applications, as well as for power sources such as wall adapters and USB ports. Its output voltage is adjustable from 0.6V to V<sub>IN, allowing for a wide range of output voltages to accommodate various devices and applications.
The LTC3428EDD boasts an impressive efficiency of up to 96%, thanks to its low R<sub>DS(ON) internal switches. This high efficiency is maintained across a broad range of output currents, contributing to extended battery life in portable applications. The device can deliver up to 600mA of continuous output current at voltages as low as 0.6V, ensuring reliable performance for high-demand applications.
Featuring a constant frequency, current mode architecture, the LTC3428EDD provides excellent line and load regulation. Its high switching frequency of up to 2.25MHz allows the use of small, low-cost capacitors and inductors, further minimizing the solution footprint. Moreover, the device includes a user-selectable Burst Mode® operation, which significantly reduces quiescent current during light loads, thus improving battery life.
Additional features of the LTC3428EDD include internal soft-start to limit inrush current during startup, a power good output voltage monitor, thermal shutdown, and overcurrent protection. These integrated features ensure a safe and robust power solution for a wide array of portable electronics, such as PDAs, smartphones, digital cameras, and other handheld devices.
In summary, the LTC3428EDD from Linear Technology is a high-performance, feature-rich step-down converter that offers a compact, efficient, and flexible solution for powering the next generation of portable devices.
