Product Overview: MAX1708EEE+T from Maxim Integrated

The MAX1708EEE+T is a high-performance, step-up DC-DC converter specifically designed by Maxim Integrated to address the needs of portable electronic devices. This compact, efficient power solution is ideal for applications requiring high voltage outputs from low voltage inputs.

Key Features

• High Efficiency: The device is capable of converting voltages with up to 94% efficiency, ensuring minimal power loss during the conversion process.
• Adjustable Output: It offers an adjustable output voltage range, which can be set from 2.7V to 5.5V using external resistors, providing flexibility for various design requirements.
• Low Input Voltage: The MAX1708EEE+T operates with an input voltage as low as 1.1V, making it suitable for battery-powered devices where maximizing the usage of available power is crucial.
• High Frequency Operation: With a switching frequency of up to 1MHz, the device allows for the use of small, low-cost inductors and capacitors, reducing the overall solution size and cost.
• Integrated MOSFET: The inclusion of an internal N-Channel MOSFET simplifies the design and reduces external component count.
• Thermal Protection: The MAX1708EEE+T is equipped with thermal shutdown protection, enhancing the safety and reliability of the device under extreme conditions.

Applications

The versatility of the MAX1708EEE+T makes it suitable for a wide range of applications, including:

• Portable Media Players
• Handheld Devices
• GPS Receivers
• Wireless and DSL Modems
• PDAs and Smartphones

Package and Quality

Supplied in a compact 16-pin QSOP package, the MAX1708EEE+T is designed for space-constrained applications. Maxim Integrated's commitment to quality ensures that each device meets the highest standards of performance and reliability.

Conclusion

With its high efficiency, adjustable output, and low input voltage capabilities, the MAX1708EEE+T from Maxim Integrated stands out as a robust power management solution for designers looking to optimize the performance of their portable and battery-powered applications.
