Product Overview

The MIC2290YML-TR is a high-efficiency, integrated switch, pulse-width modulation (PWM) boost regulator from Microchip Technology. Ideal for compact and power-sensitive applications, this regulator is designed to step up the voltage from a power supply to a higher level, efficiently managing power distribution within electronic devices.

Key Features

• Output Voltage: The MIC2290YML-TR offers an adjustable output voltage range, which is a significant advantage for designers looking to tailor the power supply to specific circuit requirements.
• High Efficiency: With its high switching frequency of up to 1.2MHz, the device allows for the use of small external components, thereby reducing the overall solution footprint and enhancing efficiency.
• Integrated Switch: The inclusion of an internal 34V / 2A switch facilitates the reduction of external part count, simplifying the design process and enhancing reliability.
• Thermal Shutdown: Safety is a priority in power management, and the MIC2290YML-TR incorporates thermal shutdown to protect the device from overheating.
• Stable with Ceramic Capacitors: The ability to operate with ceramic capacitors, which have low equivalent series resistance (ESR), results in stable operation with high-quality output filtering.

Applications

The MIC2290YML-TR is versatile and can be used in a variety of applications, including but not limited to:

• Battery-powered devices
• Portable media players
• Handheld devices
• LED lighting
• Wireless networking devices

Package and Quality

Supplied in a compact 10-pin 3x3mm MLF® package, the MIC2290YML-TR is designed for space-constrained applications. Additionally, the product is available in tape and reel packaging, making it suitable for automated mass production processes. Microchip Technology ensures high standards of quality and reliability for their products, and the MIC2290YML-TR is no exception, delivering performance that designers can trust.

With its wide input voltage range and the ability to deliver a high output voltage, the MIC2290YML-TR is a robust solution for boosting power in a variety of electronic systems.
