74HCT125PW,118

Part No 74HCT125PW,118
Manufacturer Nexperia USA Inc.
Catalog Logic - Buffers, Drivers, Receivers, Transceivers
Description IC BUFFER DVR TRI-ST QD 14TSSOP
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Nexperia USA Inc.
Packaging Reel - TR
Status Active
Logic Type Buffer, Non-Inverting
Number of Elements 4
Number of Bits per Element 1
Output Type Push-Pull
Current - Output High, Low 6mA, 6mA
Supply Voltage - Operating 4.5 V to 5.5 V
Temperature Range - Operating -40°C to 125°C (TA)
Mounting SMD (SMT)
Case / Package 14-TSSOP
Win Source Part Number 1008601-74HCT125PW,118
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian 74HCT125PW,118 CAD Model

Description

74HCT125PW,118 from Nexperia USA Inc. is a logic buffer/driver device commonly considered for digital signal interfacing, bus isolation, and general-purpose logic buffering in embedded and industrial electronic designs. In applications where engineers need to improve signal integrity, separate logic domains, or control data flow between subsystems, parts in this category are widely used because they help support cleaner digital communication and system-level flexibility. This device may be relevant in consumer electronics, control boards, computing peripherals, and communication support circuits where standard logic functions are required. The current lifecycle status for 74HCT125PW,118 is information not available in the provided data, so design teams should confirm ongoing production status directly with Nexperia or through authorized channels before committing to long-term programs. RoHS compliance information is also not available in the provided input and should be verified against the latest manufacturer datasheet, declaration, or distributor compliance documentation before procurement.
