PBSS8510PA,115 Nexperia USA Inc. PBSS8510PA,115 label picture
Same model may have multiple batches, images only for reference.
PBSS8510PA,115 Nexperia USA Inc. PBSS8510PA,115 label picture
PBSS8510PA,115 Nexperia USA Inc. PBSS8510PA,115 label picture
Same model may have multiple batches, images only for reference.

PBSS8510PA,115

Part No PBSS8510PA,115
Manufacturer Nexperia USA Inc.
Catalog Transistors (BJT) - Single
Description TRANS NPN 100V 5.2A SOT1061
Datasheet
PBSS8510PA,115 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Nexperia USA Inc.
Packaging Reel - TR
Status Active
Transistor Polarity NPN
Maximum Current Collector 5.2A
VCEO Maximum Collector-Emitter Breakdown Voltage 100V
Max Vce (sat) 340mV @ 260mA, 5.2A
Collector Cut-off Current(Max) 100nA
Typical Gain (hFE) (Min) 95 @ 2A, 2V
Maximum Power Dissipation 2.1W
Frequency - Transition 150MHz
Temperature Range - Operating 150°C (TJ)
Mounting SMD (SMT)
Case / Package 3-HUSON (2x2)
Win Source Part Number 1086543-PBSS8510PA,115
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian PBSS8510PA,115 CAD Model

Description

The PBSS8510PA,115 is a Nexperia USA Inc. product. It is a part of the 3-HUSON package and is mounted using SMT.

  • Polarity: NPN
  • Maximum Collector-Emitter Breakdown Voltage: 100V
  • Maximum Current Collector: 5.2A
  • Maximum Power Dissipation: 2.1W
