PSMN5R6-60YLX Nexperia USA Inc. PSMN5R6-60YLX real image14966
Same model may have multiple batches, images only for reference.
PSMN5R6-60YLX Nexperia USA Inc. PSMN5R6-60YLX real image14966
PSMN5R6-60YLX Nexperia USA Inc. PSMN5R6-60YLX real image14966
Same model may have multiple batches, images only for reference.

PSMN5R6-60YLX

Part No PSMN5R6-60YLX
Manufacturer Nexperia USA Inc.
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 60V LFPAK56 / Trans MOSFET N-CH 60V 100A 5-Pin(4+Tab) LFPAK T/R
Datasheet
PSMN5R6-60YLX Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Nexperia USA Inc.
Packaging Reel package
Channel Type Type N
Technology MOSFET
Drain Source Voltage 60V
Current - Continuous Drain (Id) @ 25°C 100A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 5V, 10V
Vgs(th) (Maximum) @ Id 2.1V @ 1mA
Gate Charge (Qg) (Maximum) @ Vgs 66.8nC @ 10V
Input Capacitance (Ciss) (Maximum) @ Vds 5026pF @ 25V
Vgs (Maximum) ±20V
Power Dissipation (Maximum) 167W (Tc)
Rds On (Maximum) @ Id, Vgs 5.6 mOhm @ 25A, 10V
Operating Temperature Range -55°C ~ 175°C (TJ)
Mounting SMD
Manufacturer Package LFPAK56, Power-SO8
Package SC-100, SOT-669
Win Source Part Number 792634-PSMN5R6-60YLX
Popularity Medium
Supply and Demand Status Limited
Family Name PSMN5R6-60YL
ECCN EAR99
Halogen Free Compliant
Estimated EOL Date 2029
Ultra Librarian 3D Model Ultra Librarian PSMN5R6-60YLX CAD Model

Description

The Nexperia USA Inc. PSMN5R6-60YL is a MOSFET with a drain source voltage of 60V.

  • Continuous Drain Current @ 25°C: 100A
  • Maximum Rds On: 5.6 mOhm @ 25A, 10V
  • Package / Case: SC-100, SOT-669
  • Mounting Type: SMD
  • Operating Temperature Range: -55°C to 175°C
  • Family: PSMN5R6-60YL
  • Category: Discrete Semiconductor Products
  • Gate Voltage for Maximum Rds On and Minimum Rds On: 5V and 10V
  • Estimated EOL Date: 2029
  • Popularity: Medium
  • Supply and Demand Status: Limited
  • ECCN Compliant: Yes
  • Country of Origin: Unknown
