C16P40FR

Part No C16P40FR
Manufacturer Nihon Inter Electronics Corporation
Catalog END - OF - LIFE
Description Low Forward Voltage drop Diode
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

RoHS State Request Verification
Manufacturer Nihon Inter Electronics Corporation
Win Source Part Number 1158368-C16P40FR
Manufacturer Homepage www.niec.co.jp
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian C16P40FR CAD Model

Description

The C16P40FR is a rectifier diode manufactured by Nihon Inter Electronics Corporation, primarily intended for high-speed switching applications where efficiency and rapid response are critical. It's suitable for circuits requiring reliable rectification and is often found in power supplies and inverters. Although designated as END-OF-LIFE, understanding its characteristics is valuable for maintaining older systems and selecting appropriate replacements.

Applications

  • Switch-mode power supplies (SMPS)
  • High-frequency inverters
  • Freewheeling diodes in inductive loads
  • DC-DC converters
  • Power factor correction (PFC) circuits

Features

  • Fast recovery time
  • High surge current capability
  • Low forward voltage drop
  • High reliability under stress
  • Compact package

Benefits

  • Increases power conversion efficiency in SMPS.
  • Reduces switching losses due to its rapid recovery.
  • Safeguards circuits from harmful voltage spikes.
  • Maintains stable operation in harsh environments.
  • Minimizes heat dissipation due to its low voltage drop.

Additional Details

The C16P40FR typically has a reverse voltage rating (VRRM) of 400V and a forward current rating (IF) of 16A. Its crucial feature is its fast recovery time (trr), typically in the nanosecond range. The operating temperature range usually extends from -55°C to +150°C. It is commonly packaged in a DO-201AD package. Given its END-OF-LIFE status, consulting datasheets for precise specifications is essential, and considering newer alternatives is recommended for new designs. The low forward voltage drop contributes to higher overall system efficiency, and the high surge current capability provides protection against transient surges.
