NXP 74HC1G32GW Single 2-Input OR Gate

The NXP 74HC1G32GW is a high-speed Si-gate CMOS device that provides a single 2-input OR gate. It is a versatile component that is designed to operate from a 2 V to 6 V power supply, making it suitable for a wide range of applications, including battery-operated devices and portable electronics.

Key Features

• Logic Type: 2-Input OR Gate
• Supply Voltage Range: 2.0 V to 6.0 V
• Operating Temperature: -40°C to +125°C
• Package: SOT-353 (SC-88A) surface-mount package
• High Noise Immunity: Ensures stable operation in noisy environments
• Low Power Dissipation: Ideal for power-sensitive applications
• High Speed: t<sub>PD of 4.5 ns at V<sub>CC = 5 V
• Latch-up Performance: Meets JESD78 Class I level B requirements
• ESD Protection: HBM JESD22-A114F exceeds 2000 V and MM JESD22-A115-A exceeds 200 V

Applications

The 74HC1G32GW is ideal for a variety of applications that require basic logic operations. Its small footprint and low power consumption make it a perfect choice for:

• Portable devices
• Power management circuits
• Control logic
• Alarm systems
• Embedded systems
